Foundation / Lower Level Plan (1/4"=1'): Layout of foundation or lower floor, with room and overall dimensions where applicable. All beam, column, pad, and joist sizing specified. Furnace and water heater locations shown.

Main Floor Plan (1/4"=1'): : Layout of main floor, with room and overall dimensions. Beam, joist, header, door and window sizes specified. Vaults and ceiling heights are shown.

Upper Floor Plan (1/4"=1'): Layout of upper floor, with room and overall dimensions. Beam, joist, header, door and window sizes specified. Vaults and ceiling heights are shown.

Front Elevation (1/4"=1'): Front view of home. Roof pitches and materials specified.



Back Elevation (1/4"=1') and Side Elevations (1/8"=1'): Back and side view with roof pitches shown.

Roof Plan (1/4"=1'): Layout of roof including roof pitches and plate heights.

Detail Sheet: Typical Foundation wall section, wall section and framing details.  Not all details relate to every plan.





Plan Package Media: The Pinnacle Plan Package contains one set of construction documents on bond. To order a Pinnacle Plan Package on high quality erasable vellum, additional bond sets or 8" x 11" sets, choose the Pricing/Ordering link.

Codes: Pinnacle plans are designed and drafted to meet average conditions and codes in the state of Kansas at the time the plan was designed. Because codes and requirements vary from location to location, Home Plans America Corp. cannot warrant compliance to any specific site or locale. Plans can be adapted to meet local building codes and site requirements, however, it is the responsibility of the purchaser and/or builder to insure compliance with local codes and site restrictions or requirements.

Copyright: The purchaser may build plans multiple times, but these plans cannot be resold, transferred or given to any other parties, under penalty of law.
